BandBreak Pro (BB×ST×SRC) — Live-Sync Indicator

📌 Overview

BandBreak Pro is a volatility + trend confirmation indicator designed to provide traders with clean breakout signals.
It synchronizes Bollinger Bands (BB), a selectable SRC line (price source), and Super trend (ST) into one unified logic.
⚡ Signals only trigger when price breaks the Bollinger Bands and the Super trend confirms the same direction.

📖 Basics & Definitions

1. Bollinger Bands (BB)

Bollinger Bands measure volatility by building an envelope around price.

Middle line (Basis) = Simple Moving Average (SMA).

Upper Band = SMA + (Multiplier × Standard Deviation).

Lower Band = SMA – (Multiplier × Standard Deviation).
👉 Meaning: A break above the upper band often suggests bullish strength, while a break below the lower band suggests bearish momentum.

2. SRC Line (Source Line)

The SRC line is a chosen price input: close, hlc3, or ohlc4.
It acts as the backbone since both BB and ST derive from it.
Benefit: Ensures everything is perfectly synchronized and avoids repainting issues.

3. Super trend (ST)

Supertrend is an ATR (Average True Range) based trend filter.
If price is above the ST line → Uptrend (Green).
If price is below the ST line → Downtrend (Red).
👉 Meaning: ST is a simple yet powerful filter to confirm trend direction and reduce false breakouts.

📌 CONCEPTS (with Calculations)

Hybrid Sync (History vs Realtime)
History: All calculations use confirmed OHLC via request.security (no lookahead) → no repaint.
Realtime: (if ON) calculations follow live chart OHLC → what you see is what you get.
Strict No-Repaint: Forces realtime bar to also use confirmed OHLC values.

👉 Formula:

if strict = true → use confirmed OHLC only
else if realtime and followChart = true → use chart OHLC
else → use confirmed OHLC


SRC Line (Selected Source)
User can select close, hlc3 = (high+low+close)/3, or ohlc4 = (open+high+low+close)/4.

This SRC drives Bollinger Bands and Supertrend.
👉 Formula:
SRC = close | hlc3 | ohlc4 (user choice)


Bollinger Bands (BB Break Logic)
Basis:
Basis = SMA(SRC, Length)

Standard Deviation:
Dev = StDev(SRC, Length)

Bands:
Upper = Basis + (Multiplier × Dev)
Lower = Basis - (Multiplier × Dev)

Breakout Filter:
UpBB = Upper × (1 + Buffer%)
DnBB = Lower × (1 – Buffer%)

👉 Meaning: Breakouts only count when price crosses filtered bands.

Supertrend (Directional Filter)
True Range:
TR = max(High – Low, |High – PrevClose|, |Low – PrevClose|)

ATR:
ATR = RMA(TR, ST_Length)

Bands:
BasicUp = (High+Low)/2 + (ST_Factor × ATR)
BasicDn = (High+Low)/2 – (ST_Factor × ATR)

Final Line (flip logic):
If Close > PrevUp → Trend = UP → use Dn line
If Close < PrevDn → Trend = DOWN → use Up line

Signal Formation (Confirmed Bar Only)
Long Condition:
Long = crossover(SRC, UpBB) AND Supertrend = UP

Short Condition:
Short = crossunder(SRC, DnBB) AND Supertrend = DOWN
Validation: Signals trigger only on barstate.isconfirmed (bar close).

🛠️ FEATURES

Clean, synced plots: Bollinger Bands, Basis line, SRC line, Supertrend line.
Hybrid sync modes: live-follow or strict no-repaint.
Bollinger controls: length, multiplier, buffer %, show/hide.
Supertrend controls: enable, ATR length, factor, show/hide.
Signal labels: BB×ST ↑ and BB×ST ↓.
Alerts: Built-in LONG/SHORT ready to use.
Overlay = true; optimized for intraday with higher label capacity.

📊 HOW TO USE
Timeframes: 5m–1H intraday; 2H–1D for swing trades.
Markets: Crypto, Forex, Indices, Equities.

Workflow:
Keep chart clean with only BandBreak Pro.
Start BB = 20 length, 2.0 multiplier. Use buffer 0.25–0.75% in choppy pairs.
Keep Supertrend ON to reduce false signals. Lower factor = faster flips.
After breakout, manage trades using S/R or BB midline.
SL = opposite ST line, TP = midline or nearest support/resistance.

⚠️ LIMITATIONS

Ranging markets may produce whipsaws.
Strict mode = safest but slower signals.
Not a strategy → no backtesting/PnL.
Parameters must be tuned for volatile/illiquid assets.
Always use with risk management.

🔔 ALERTS

BB×ST LONG → SRC crosses above upper band + ST = UP.
BB×ST SHORT → SRC crosses below lower band + ST = DOWN.
👉 Recommended: “Once Per Bar Close”.

NOTES

Buffer % = micro filter, useful for high-volatility assets.
Higher ST factor = fewer flips, more trend fidelity.
Lower ST factor = faster flips, more frequent signals.


🌟 Why BandBreak Pro is Unique

✅ Both BB and ST are calculated from the same hybrid OHLC SRC source → perfectly aligned & repaint-free.
✅ Only issues dual-confirmation signals → fewer false breakouts.
✅ Beginner-friendly (clear definitions included) + Pro-level customization (buffer %, sync modes).
✅ Multi-market: Crypto, Forex, Indices, Stocks.

🙏 Thanks

Bollinger Bands = John Bollinger’s volatility framework.
Supertrend = ATR-based classic TA tool.
SRC + Hybrid Sync = original implementation adapted for TradingView.
