Price Action Trading System v0.3 by JustUncleL

This is an updated and improved version of my "Price Action Trading strategy". I have added two extra optional filters, one is a trend direction filter based on the MACD slow EMA (17), blue line, and the other is a RSI (7) filter which works similarly to CCI (14) but slightly different dynamics (thank you to gianfranco60 for the suggestion). Also made a couple of corrections:
- input for lenLower minval=1 should be maxval=-1
- one bar pullback did not reset trigger, missing some alerts
Some Notes about usage:
- this is an alert indicator not a signal generator, each alert is a strong trend continuance candidate,
but should be treated on it's own merits by looking at chart dynamics and market conditions.
- will work well on trending markets only.
- works best on the first alert after MACD cross over.
- don't take trades when MACD and signal are close together .
- don't trade when channel and slow MA are flat or close together or
chopper (yellow and blue MA cross over quickly over short period).
Script open-source

Nello spirito di condivisione promosso da TradingView, l'autore (al quale vanno i nostri ringraziamenti) ha deciso di pubblicare questo script in modalità open-source, così che chiunque possa comprenderlo e testarlo. Puoi utilizzarlo gratuitamente, ma il riutilizzo del codice è subordinato al rispetto del Regolamento. Per aggiungerlo al grafico, mettilo tra i preferiti.

Vuoi usare questo script sui tuoi grafici?
//Name: Price Action Channel Trading System v0.3 by JustUncleL
//Created By: JustUncleL on 3 Aug 2016
//Version: 0.3
//  This is an implementation of 'Price Action Channel, “The Gold line” Trading System'
//  for Binary Options, originally a scapling system, but without the MA cross "Arrow1".
//  This is a Trend following price action system.
//  To complete the setup instead of the two "Chandelier Stop" indications,
//  I replaced them with a MACD(12,17,8) indicator.
//  This is suitable for 15min charts, with 2 to 4 candle (30min to 60min) expiry.
//  Call Entry:
//  - Green Triangle, confirmed by MACD background green.
//  - CCI Candles aqua.
//  - For best call entry wait for the price retrace back to the gold line,
//    back inside channel also works well.
//  Put Entry:
//  - Red Triangle, confirmed by MACD background red.
//  - CCI Candles black.
//  - For best put entry wait for the price retrace on the gold line,
//    back inside channel also works well.
//  - will work well on trending patterns only.
//  - works best on the first alert after MACD cross over.
//  - don't take trades when MACD and signal are close together.
//  - don't trade when channel and slow MA are flat or close together or
//    chopper (yellow and blue MA cross over quickly over short period).
//  0.3 : Added optional filters for trend direction from MACD slow EMA(17)
//        and also RSI(7) filter.
//        Some corrections:
//        - input for lenLower minval=1 should be maxval=-1
//        - one bar pullback did not reset trigger, missing some alerts
//  0.2 : Use MACD instead of Chandelier Stop for filtering, giving
//        a simplier looking chart.
//  0.1 : Original version.
// reference:
//  - Chandelier Stop by pipCharlie (not used in this version)
//  - http://www.forexstrategiesresources.com/scalping-forex-strategies/73-price-action-channel-the-gold-line/
//  - Used some ideas from RSI Candles by glaz
study(title="Price Action Trading System v0.3 by JustUncleL",overlay = true, shorttitle="CCIPAT v0.3 by JustUncleL")
len = input(14, minval=1, title="CCI Length")
lenUpper = input(75, minval=1, title="CCI UpLevel")
lenLower = input(-75, maxval=-1, title="CCI DownLevel")
bars_on = input(true, title="Color CCI Bars")
src = input(close,title="CCI Source")
lenLo   = input(5, minval=2, title="Low Channel Length")
lenHi   = input(5, minval=2, title="High Channel Length")
lenMe = input(4, minval=1, title="Median Channel Length")
fastLength = input(12, minval=1,title="MACD Fast Length")
slowLength=input(17,minval=1,title="MACD Slow Length")
signalLength=input(8,minval=1,title="MACD Signal Length")
rsiLen  = input(7,minval=2,title="RSI length")
rsiUpper= input(70,minval=50,maxval=100,title="RSI Upper limit")
rsiLower= input(30,maxval=50,minval=0,title="RSI Lower Limit")
filterM = input(true,title="Use MACD confilter filter")
filterR = input(true,title="Use RSI confirm filter")
filterE = input(true,title="Use Trend direction filter")
dCandles= input(4,minval=2,title="Direction test Candles")
rsiVal = rsi(src,rsiLen)
// Calculate MACD and color background
fastMC = ema(src, fastLength)
slowMC = ema(src, slowLength)
macd = fastMC - slowMC
signal = sma(macd, signalLength)
OutputSignal = signal > macd ? 1 : signal < macd ? -1 : 0
bgcolor(OutputSignal>0?red: OutputSignal<0?green:yellow, transp=90)
plot(slowMC,color=blue,transp=0,title="Slow EMA trend line", linewidth=2)

// Calculate and draw the Price Action channel
emaLo = ema(low,lenLo)
emaHi = ema(high,lenHi)
emaMe = ema(hl2,lenMe)
plot(emaLo,title="Low Price Line",style=line,color=gray,transp=0,linewidth=2)
plot(emaHi,title="High Price Line",style=line,color=gray,transp=0,linewidth=2)
plot(emaMe,title="Median Price Line",style=line,color=orange,transp=0,linewidth=2)

// Calculate CCI
cciVal = cci(src, len)

// Calculate CCI indicating continuance of trend.
isup = cciVal > lenUpper
isdown = cciVal < lenLower
barcolor(bars_on ? isup ? aqua : isdown ? black : na : na )

// Check have alert and use MACD filter
cciup_alert = isup and close>open and (not filterR or rsiVal>rsiUpper) and (not filterM or OutputSignal<0) and
              (not filterE or (emaMe>slowMC and rising(slowMC,dCandles))) ? na(cciup_alert[1]) ? 1 : cciup_alert[1]+1 : 0
ccidn_alert = isdown and close<open and (not filterR or rsiVal<rsiLower) and (not filterM or OutputSignal>0) and
              (not filterE or (emaMe<slowMC and falling(slowMC,dCandles))) ? na(ccidn_alert[1]) ? 1 : ccidn_alert[1]+1 : 0
plotshape(cciup_alert==1? cciup_alert : na, title="CCIPAT Up Arrow", style=shape.triangleup,location=location.belowbar, color=olive, transp=0, size=size.small)
plotshape(ccidn_alert==1? ccidn_alert : na, title="CCIPAT Down Arrow", style=shape.triangledown,location=location.abovebar, color=red, transp=0, size=size.small)

// generate an alert if required.
alertcondition(cciup_alert==1 or ccidn_alert==1, title="CCIPAT Alert", message="CCIPAT Alert")



I am a new trader, can you pls tell me how to download this script.
I find its interesting Price Action trading System.
can I test it, Thank you.
+39 Rispondi
Your strategy semms to me very attractive. It's possible to get signals alerts on mail or sms.
Thanks for answer.
Kind regards
+8 Rispondi
JustUncleL srecoenator
@srecoenator, The TradingView Alarm system can be setup to provide SMS or email alerts.
+2 Rispondi
srecoenator JustUncleL
@JustUncleL, Thanks!
I will try set up my self :)
Kind regards
+3 Rispondi
Hello Sir, May I know what the black candles represent. It's an interesting indicator. Thank you for the efforts.
+6 Rispondi
shrav1988 shrav1988
@JustUncleL Hello Sir, Please ignore my question. I got the information from code. Thank you for briefing.
+1 Rispondi
Hello how are ? Thank for the help youve been to the trading community. I love this system, I was wondering if you would happen to have this system file for the mt4 Platform?
+1 Rispondi
Hello, thank you for the strategy, I wanted to know whether you have any backtest data for this strategy
Great job! Thx!
